Operating Modes, Program Operation (K1)
10.2 Operating modes
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
171
10.2.3 Monitoring functions in the individual modes
Overview of monitoring functions
Different monitoring functions are active in individual operating modes.
Table 10- 3 Monitoring functions and interlocks
Mode of operation AUTO JOG MDI
Functions 1 2 3 1 3 4 3 5 3 1 2 3 6 7
Axis-specific monitoring functions or when positioning the spindle
SW limit switch + x x x x x x x
SW limit switch – x x x x x x x
HW limit switch + x x x x x x x x x x x x x x
HW limit switch – x x x x x x x x x x x x x x
Exact stop coarse/fine x x x x x x x x x x x x x x
Clamping tolerance x x x x x x x x x x x x x x
DAC limit
(analog spindle)
x x x x x x x x x x x x x x
Contour monitoring x x x x
x x x
Spindle-specific monitoring functions
Speed limit exceeded x x x x x x
Spindle is stationary x x x x x x x x x x x x x x
Spindle synchronized x x x x x x
Speed in setpoint range x
Maximum permissible speed x x x x
x x
Encoder frequency limit x x x x x x
x: Monitoring is active in this status
1: Channel in reset
2: Channel interrupted
3: Channel active
4: Channel interrupted JOG during AUTOMATIC interruption
5: Channel interrupted JOG during MDA interruption
6: Channel active JOG in MDA during MDA interruption
7: Channel active JOG in MDA
