EMERGENCY OFF (N2)
14.4 Data lists
Turning, Milling, Nibbling
264 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
PLC I/Os
The PLC user program must switch the PLC I/Os to the correct state for operation of the
machine.
Reset
The EMERGENCY STOP state cannot be reset solely by IS "Reset" (V3000 0000.7) (see
diagram above).
Power off/on
Power off/on (POWER ON) cancels the EMERGENCY OFF state unless IS "EMERGENCY
OFF "
(V2600 0000.1) is still set.
14.4 Data lists
14.4.1 Machine data
Number Identifier Name
Axis-specific
36610 AX_EMERGENCY_STOP_TIME Length of the braking ramp for error
states
36620 SERVO_DISABLE_DELAY_TIME Shutdown delay controller enable
14.4.2 Interface signals
Number Bit Name
General
V2600 0000 .0 Braking on the contour with EMERGENCY STOP
V2600 0000 .1 EMERGENCY STOP
V2600 0000 .2 Acknowledge EMERGENCY STOP
V2700 0000 .1 EMERGENCY STOP active
Operating mode signal area
V3000 0000 .7 Reset
