Siemens SINUMERIK 802D sl Function Manual

Operating Modes, Program Operation (K1)
10.7 Data lists
Turning, Milling, Nibbling
202 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
10.7 Data lists
10.7.1 Machine data
NC-specific machine data
Number Identifier Name
General
10702 IGNORE_SINGLEBLOCK_MASK Prevent single-block stop
11450 SEARCH_RUN_MODE Block search parameter settings
11602 ASUP_START_MASK Ignore stop conditions for ASUB
11604 ASUP_START_PRIO_LEVEL Priorities for ASUP_START_MASK
11620 PROG_EVENT_NAME Program name for program event
Basic machine data of channel
Number Identifier Name
Channel-specific
20050 AXCONF_GEOAX_ASSIGN_TAB[n] Assignment between geometry axis and
channel axis [GEOaxis no.]: 0...2
20060 AXCONF_GEOAX_NAME_TAB[n] Geometry axis name in channel [GEOaxis
no.]: 0...2
20070 AXCONF_MACHAX_USED[n] Machine axis number valid in channel
[channel axis no.]: 0...4
20080 AXCONF_CHANAX_NAME_TAB[n] Channel axis name in channel [channel axis
no.]: 0...4
20100 DIAMETER_AX_DEF Geometry axis with transverse axis function
20106 PROG_EVENT_IGN_SINGLEBLOCK Prog events ignore the single block
20107 PROG_EVENT_IGN_INHIBIT Prog events ignore the read-in disable
20108 PROG_EVENT_MASK Eventdriven program calls
20109 PROG_EVENT_MASK_PROPERTIES Prog event properties
20110 RESET_MODE_MASK Initial setting at RESET
20112 START_MODE_MASK Initial setting at special NC Start after power-
up and at RESET
20116 IGNORE_INHIBIT_ASUP Execute user ASUBs completely in spite of
readin disable
20117 IGNORE_SINGLEBLOCK_ASUP Process user ASUBs completely in spite of
single-block processing
20700 REFP_NC_START_LOCK NC-Start disable without reference point
21000 CIRCLE_ERROR_CONST Circle end point monitoring constant
