Operating Modes, Program Operation (K1)
10.2 Operating modes
Turning, Milling, Nibbling
170 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
10.2.2 Functional possibilities in the individual modes
Overview of the functions
You see from the following table which function can be selected in which operating mode
and in which operating state.
Table 10- 2 Functional possibilities in the individual modes
Mode of operation AUTOMATIC JOG MDI
Functions 1 2 3 1 3 4 3 5 3 1 2 3 6 7
Loading a part program from
outside through "Services"
sb sb sb sb sb sb sb sb
Processing a part
program/block
s s b s s b
Block search s s b
Reference point approach
via part program command
(G74)
sb sb
s: Function can be started in this status
b: Function can be processed in this status
1: Channel in reset
2: Channel interrupted
3: Channel active
4: Channel interrupted JOG during AUTOMATIC interruption
5: Channel interrupted JOG during MDA interruption
6: Channel active JOG in MDA during MDA interruption
7: Channel active JOG in MDA
