Siemens SINUMERIK 802D sl Function Manual

Operating Modes, Program Operation (K1)
10.7 Data lists
Turning, Milling, Nibbling
204 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
10.7.3 Interface signals
Operating mode signals
Number Bit Name
PLC to NCK
V3000 0000 .0 AUTOMATIC mode
V3000 0000 .1 MDA mode
V3000 0000 .2 JOG mode
V3000 0000 .4 Mode change disable
V3000 0000 .7 RESET
V3000 0001 .2 Machine function REF
NCK to PLC
V3100 0000 .0 Active mode AUTOMATIC
V3100 0000 .1 Active mode MDA
V3100 0000 .2 Active JOG mode
V3100 0000 .3 802 READY
V3100 0001 .2 Active machine function REF
Channel signals
Number Bit Name
PLC to NCK
V3200 0000 .4 Activate single block
V3200 0000 .5 Activate M01
V3200 0000 .6 Activate dry run feed
V3200 0001 .0 Activate referencing
V3200 0001 .7 Activate program test
V3200 0002 .0 Block skip
V3200 0006 .0 Feed disable
V3200 0006 .1 Read-in disable
V3200 0006 .2 Delete distance-to-go
V3200 0006 .3 Delete UP number of passes
V3200 0006 .4 Program level abort
V3200 0006 .6 Rapid traverse override active
V3200 0006 .7 Feed rate override active
V3200 0007 .0 NC Start disable
V3200 0007 .1 NC Start
V3200 0007 .2 NC Stop at block limit
V3200 0007 .3 NC stop
V3200 0007 .4 NC Stop axes plus spindles
