Punching and Nibbling (N4)
15.8 Data lists
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
301
15.8 Data lists
15.8.1 Machine data
Number Identifier Name
General
11450 SEARCH_RUN_MODE Block search parameter settings
Channel-specific
26000 PUNCHNIB_ASSIGN_FASTIN Hardware assignment for input-byte with
stroke control
26002 PUNCHNIB_ASSIGN_FASTOUT Hardware assignment for output-byte with
stroke control
26004 NIBBLE_PUNCH_OUTMASK[n]) Mask for quick output bits
26006 NIBBLE_PUNCH_INMASK[n] Mask for quick input bits
26010 PUNCHNIB_AXIS_MASK Definition of punching and nibbling axes
26014 PUNCH_PATH_SPLITTING Activation of automatic path segmentation
26016 PUNCH_PARTITION_TYPE Behavior of single axes with active automatic
path segmentation
26018 NIBBLE_PRE_START_TIME Automatically activated pre-initiation time
26020 NIBBLE_SIGNAL_CHECK Monitoring of the input signal
15.8.2 Setting data
Number Identifier Description
Channel-specific
42400 PUNCH_DWELL_TIME Dwell time
42402 NIBPUNCH_PRE_START_TIME Pre-start time
42404 MINTIME_BETWEEN_STROKES Minimum time interval between two
consecutive strokes
15.8.3 Interface signals
Number Bit Name
Signals to channel
V3200 0003 .0 Stroke enable
V3200 0003 .1 Manual stroke initiation
V3200 0003 .2 Stroke suppression
V3200 0003 .3 Stroke inoperative
