Spindle (S1)
20.9 Data lists
Turning, Milling, Nibbling
366 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
Number Identifier Name
35130 * GEAR_STEP_MAX_VELO_LIMIT[n] Maximum speed of gear stage
35140 * GEAR_STEP_MIN_VELO_LIMIT[n] Minimum speed of gear stage
35150 SPIND_DES_VELO_TOL Spindle speed tolerance
35160 SPIND_EXTERN_VELO_LIMIT Spindle speed limitation via PLC
35200 * GEAR_STEP_SPEEDCTRL_ACCEL[n] Acceleration in speed control mode
35210 * GEAR_STEP_POSCTRL_ACCEL[n] Acceleration in position control mode
35300 SPIND_POSCTRL_VELO Position control activation speed
35310 SPIND_POSIT_DELAY_TIME[n] Positioning delay time
35350 SPIND_POSITIONING_DIR Positioning direction of rotation for a nonsynchronized spindle
35400 SPIND_OSCILL_DES_VELO Reciprocating speed
35410 SPIND_OSCILL_ACCEL Oscillation acceleration
35430 SPIND_OSCILL_START_DIR Starting direction during oscillation
35440 SPIND_OSCILL_TIME_CW Oscillation time for M3 direction
35450 SPIND_OSCILL_TIME_CCW Oscillation time for M4 direction
35500 SPIND_ON_SPEED_AT_IPO_START Feed enable with spindle in setpoint range
35510 SPIND_STOPPED_AT_IPO_START Feed enable with stationary spindle
36060 STANDSTILL_VELO_TOL Threshold velocity "Axis/spindle stationary"
36200 * AX_VELO_LIMIT [n] Threshold value for velocity monitoring
36300 ENC_FREQ_LIMIT Encoder limit frequency
36302 ENC_FREQ_LIMIT_LOW Encoder limit frequency resynchronization
36720 DRIFT_VALUE Drift basic value
The machine data marked with * is contained in the parameter set for a gear stage.
20.9.2 Setting data
Number Identifier Name
General
41200 JOG_SPIND_SET_VELO JOG velocity for the spindle
Spindle-specific
43210 SPIND_MIN_VELO_G25 Programmable spindle speed limit G25
43220 SPIND_MAX_VELO_G26 Programmable spindle speed limit G26
43230 SPIND_MAX_VELO_LIMS Programmable spindle speed limit G96
20.9.3 Interface signals
Number Bit Name
Axis-specific
VD30x 0000 - M function for the spindle (DINT), axis-specific
