Tool: Compensation and Monitoring (W1)
25.6 Data lists
Turning, Milling, Nibbling
434 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
25.6 Data lists
25.6.1 Machine data
Number Identifier Name
General
18080 ** MM_TOOL_MANAGEMENT_MASK Memory reservation for the tool
monitoring
Channel-specific
20310 ** TOOL_MANAGEMENT_MASK Activation of the tool monitoring
22360 TOOL_PARAMETER_DEF_MASK Definition of tool parameters
22550 TOOL_CHANGE_MODE New tool offsets with M function
** This machine data is not available with 802D sl value.
25.6.2 Interface signals
Number Bit Name
Channel-specific
V1900 5001 .0 Update tool list
V2500 0008 .0 T function 1 change
V2500 0010 .0 D function 1 change
VD2500 2000 - T function 1
VD2500 5000 - D function 1
V2500 1000 .6 M6
V3200 0013 .5 Deactivate workpiece counter
V5300 0000 .0 Tool pre-warning limit reached
V5300 0000 .1 Tool limit value reached
VD5300 1000 - T number for tool pre-warning limit
VD5300 1004 - T number for tool limit value
