Tangential Control (T3)

22.5 Data lists

Turning, Milling, Nibbling

Function Manual, 11/2012, 6FC5397-1CP10-5BA0

389

N70 WALIMON ; Switch on working area limitation

N80 X100

N90 X10 ; Before this block is processed, rotary axis C is

repositioned in

; an intermediate block, C' = -60 degrees.

N200 M2

22.5 Data lists

Machine data

Number Identifier Name

Axis-specific

37400 EPS_TLIFT_TANG_STEP Tangential angle for corner recognition

37402 TANG_OFFSET Default angle for tangential follow-up control

Default Chapter5
