Siemens SINUMERIK 802D sl Function Manual

Manual and Handwheel Travel (H1)
8.6 Data lists
Turning, Milling, Nibbling
154 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
8.6 Data lists
8.6.1 Machine data
Number Identifier Name
General information
10000 AXCONF_MACHAX_NAME_TAB[n] Machine axis name [n = axis index]
10735 JOG_MODE_MASK Settings for JOG mode
11310 HANDWH_REVERSE Defines movement in the opposite direction
11320 HANDWH_IMP_PER_LATCH[0]...[2] Handwheel pulses per locking position
11346 HANDWH_TRUE_DISTANCE Handwheel path or velocity specification
Channel-specific
20060 AXCONF_GEOAX_NAME_TAB[n] Geometry axis in channel [n = geometry axis index]
20100 DIAMETER_AX_DEF Geometry axes with transverse axis functions
Axis/spindle-specific
30600 FIX_POINT_POS[n] Fixed-point positions for the axis
30610 NUM_FIX_POINT_POS Number of fixed-point positions for an axis
32000 MAX_AX_VELO Maximum axis velocity
32010 JOG_VELO_RAPID Rapid traverse in JOG mode
32020 JOG_VELO JOG axis velocity
32300 MAX_AX_ACCEL Axis acceleration
32420 JOG_AND_POS_JERK_ENABLE Enable for axis-spec. jerk limitation
32430 JOG_AND_POS_MAX_JERK Axis-specific jerk
35130 GEAR_STEP_MAX_VELO_LIMIT[0]...[5] Maximum velocity for gear stage/spindle
8.6.2 Setting data
Number Identifier Name
General information
41010 JOG_VAR_INCR_SIZE Size of variable increment for INC/handwheel
41110 JOG_SET_VELO JOG velocity for linear axes
41130 JOG_ROT_AX_SET_VELO JOG speed for rotary axes
41200 JOG_SPIND_SET_VELO JOG velocity for the spindle
