Kinematic Transformation (M1)
12.5 Data lists
Turning, Milling, Nibbling
248 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
12.5 Data lists
12.5.1 Machine data
Number Identifier Name
Channel-specific
20110 RESET_MODE_MASK Definition of control basic setting after run-up and RESET/part
program end (access only possible at protection level 1/1)
20140 TRAFO_RESET_VALUE Initial setting: Transformation active after Reset
22534 TRAFO_CHANGE_M_CODE M code for transformation changeover
24100 TRAFO_TYP_1 Type of 1st transformation, possibly with axis sequence
24110 TRAFO_AXES_IN_1 Axis assignment at input of 1st transformation
24120 TRAFO_GOEAX_ASSIGN_TAB_1 Geo-axis assignment for 1st transformation
24200 TRAFO_TYP_2 Type of 2nd transformation, possibly with axis sequence
24210 TRAFO_AXES_IN_2 Axis assignment at input of 2nd transformation
24220 TRAFO_GOEAX_ASSIGN_TAB_2 Geo-axis assignment for 2nd transformation
24800 TRACYL_ROT_AX_OFFSET_1 Deviation of rotary axis from zero position in degrees (1st TRACYL)
24810 TRACYL_ROT_SIGN_IS_PLUS_1 Sign of rotary axis for TRACYL (1st TRACYL)
24820 TRACYL_BASE_TOOL_1 Distance of tool zero point from origin of geo-axes (1st TRACYL)
24900 TRANSMIT_ROT_AX_OFFSET_1 Deviation of rotary axis from zero position in degrees (1st
TRANSMIT)
24910 TRANSMIT_ROT_SIGN_IS_PLUS_1 Sign of rotary axis for TRANSMIT (1st TRANSMIT)
24911 TRANSMIT_POL_SIDE_FIX_1 Limitation of working range in front of/behind pole, 1st transformation
24920 TRANSMIT_BASE_TOOL_1 Distance of tool zero point from origin of geo-axes (1st TRANSMIT)
12.5.2 Interface signals
Number Bit Name
Channel-specific
V3800 0001 .6 Transformation active
