Auxiliary Function Outputs to PLC (H2)
9.4 Grouping of auxiliary functions
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
161
Ungrouped auxiliary functions
The output of auxiliary functions that are not assigned to groups is made with the movement.
Configuring example:
Distribute 8 auxiliary functions to 7 groups:
Group 1: M0, M1, M2 (M17, M30) - by default, should be kept
Group 2: M3, M4, M5 (M70) - by default, should be kept
Group 3: S functions - by default, should be kept
Group 4: M78, M79
Group 5: M80, M81
Group 6: H1=10, H1=11, H1=12
Group 7: all T functions
Password for protection level 2 is set.
Make entry in MD11100 AUXFU_MAXNUM_GROUP_ASSIGN=8.
Then, turn off the control and turn it on again or perform the control start-up through the
softkey and define the remaining machine data with a subsequent restart of the control.
Table 9- 3 Entries into the machine data for the example
Index n MD22000
(GROUP)
MD22010
(TYPE)
MD22020
(EXTENSION)
MD22030
(VALUE)
0 4 M 0 78
1 4 M 0 79
2 5 M 0 80
3 5 M 0 81
4 6 H 1 10
5 6 H 1 11
6 6 H 1 12
7 7 D 0 -1
