Siemens SINUMERIK 802D sl Function Manual

Operating Modes, Program Operation (K1)
10.3 Processing a part program
Turning, Milling, Nibbling
Function Manual, 11/2012, 6FC5397-1CP10-5BA0
189
Table 10- 12 Responses to operator or program actions
Situat
ion
Channel
status
Program status Active mode Operator or program action
(Situation after the action)
R U A N U S A A M J
1 x x x RESET (4)
2 x x x RESET (5)
3 x x x RESET (6)
4 x x x NC Start (13); mode change
(5 or 6)
5 x x x NC Start (14); mode change
(4 or 6)
6 x x x Direction key (15); mode change
(4 or 5)
7 x x x NC Start (14)
8 x x x NC Start (15)
9 x x x NC Start (13); mode change
(10 or 11)
10 x x x NC Start (16); mode change
(9 or 11)
11 x x x Direction key (17); mode change
(9 or 10)
12 x x x NC Start (13); mode change
(10 or 11)
13 x x x NC Stop (12)
14 x x x NC Stop (7); at block end (5)
15 x x x NC Stop (8); at JOG end (6)
16 x x x NC Stop (10); at block end (10)
17 x x x NC Stop (11); at JOG end (11)
Description
Channel status:
R: aborted
U: interrupted
A: running
Program status:
N: aborted
U: interrupted
S: stopped
A: running
Operating modes:
A: AUTOMATIC
M: MDA
J: JOG
