Tool: Compensation and Monitoring (W1)
25.5 Special handling of tool compensation
Turning, Milling, Nibbling
432 Function Manual, 11/2012, 6FC5397-1CP10-5BA0
The assignment of the tool lengths 1 to 3 to the geometry axes for turning tools (tool types
500 to 599) results from the value of the setting data SD42940 in accordance with the
following table:
Plane/value Length 1 Length 2 Length 3
17 Y X Z
18*) X Z Y
19 Z Y X
-17 X Y Z
-18 Z X Y
-19 Y Z X
*) Each value not equal to 0 which is not equal to one of the six listed values is evaluated as
the value for 18.
With respect to the values with a negative sign the assignment of length 3 is identical, length
1 and 2 are exchanged - compared to the assignment with the corresponding positive
values.
The following table shows the assignment of the tool lengths 1 to 3 to the geometry axes for
drills / milling cutters (tool types 100 to 299):
Plane/value Length 1 Length 2 Length 3
17*) Z Y X
18 Y X Z
19 X Z Y
-17 Z X Y
-18 Y Z X
-19 X Y Z
*) Each value not equal to 0 which is not equal to one of the six listed values is evaluated as
the value for 17.
With respect to the values with a negative sign the assignment of length 1 is identical, length
2 and 3 are exchanged - compared to the assignment with the corresponding positive
values.
Note
For representation in tables, it is assumed that geometry axes 1 to 3 are named X, Y, Z. The
axis order (1st, 2nd and 3rd geometry axis) and not the axis identifier determines the
assignment between an offset and an axis.
