Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
26 6FC5397-4EP10-0BA8, 07/2018
SINAMICS V70 spindle drive rating plate
Explanation of SINAMICS V70 spindle drive article numbers
Data position of the article
number
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Article number
6
S
L
3
2
1
0
-
5
D
●
❑
❑
-
❑
U
A
0
Mains voltage: 3 AC 380 V
to 480 V
E
Frame size
Motor output
power
FSB
3.7 kW
2
1
1
FSC
3.7 kW
2
1
3
7.5 kW
2
2
0
FSD
11 kW
2
3
0
15 kW
2
4
0
Components in the SIMOTICS M-1PH1 main motor package
Component
Illustration
Shaft height
(mm)
Rated power
(kW)
Rated speed
(rpm)
Article number
1)
SIMOTICS M-
1PH1 main
motor
100
3.7
1500
1PH1101-1❑F1❑-❑GA0
3.7
1000
1PH1103-1❑D1❑-❑GA0
5.5
1500
1PH1103-1❑F1❑-❑GA0
5.5
1000
1PH1105-1❑D1❑-❑GA0
7.5
1500
1PH1105-1❑F1❑-❑GA0
132
7.5
1000
1PH1131-1❑D1❑-❑GA0
11
1500
1PH1131-1❑F1❑-❑GA0
11
1000
1PH1133-1❑D1❑-❑GA0
15
1500
1PH1133-1❑F1❑-❑GA0
User documen-
tation
SIMOTICS M-1PH1 Main Motor Installation Guide
1)
For more information about the article numbers, see the motor article number explanation described later in this section.
