Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
343
HMI
Syntax
Used identifiers and their meanings
<state type="notpressed" />
<navigation>Main</navigation>
</softkey_back>
</menu>
MENU
: defines the start menu containing the softkey
description and the dialog to be opened.
<form name="Setting">
FORM
: defines the description of the desired user
dialog.
②
<paint>
PAINT
: defines the desired texts and images which
are to be displayed in the dialog box.
<text xpos="15" color="#000000"
ypos="60">Switch Fixture</text>
...
</paint>
<init>
INIT
: defines the desired input elements and hotlinks
for the dialog form
③
<caption>Machine operation set-
ting</caption>
CAPTION
: defines the title of the desired dialog box.
④
<control name="Toggle1" xpos="346"
ypos="60" height="16" width="80"
refvar="plc/db1400.dbx9.0" hotlink="true"
fieldtype="combobox">
CONTROL
: defines the desired control elements.
<item value="1">Vacuum</item>
<item value="0">Pneumatic</item>
</control>
...
</init>
INIT
: defines the desired input elements and hotlinks
for the dialog form
</form>
FORM
: defines the description of the desired user
dialog.
Generating the XML file for creating the parameter setting menu
General information
● Type of addressed components: machine and setting data
● Menu function on the HMI: making settings for frequently used Z axis parameters
