Commissioning Manual
344 6FC5397-4EP10-0BA8, 07/2018
User dialog and XML file examples
Pressed ⇒
Used identifiers and their meanings
<let name="var2" type="int"></let>
: defines the desired local variable under the
: defines the start menu containing the softkey
description and the dialog to be opened.
<OPEN_FORM name="Parameter" />
: opens the desired dialog form given
â‘
<softkey position="1"
type="user_controlled">
: defines the properties and responses of
the desired softkeys.
<state type="notpressed" />
<caption>Machine%nOperation</caption>
<navigation>Setting</navigation>
