Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
398 6FC5397-4EP10-0BA8, 07/2018
No.
Name
Default
Range
Type
Unit
Activating
32000
MAX_AX_VEL
O
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm CF
Maximum axis velocity
32010
JOG_VELO_R
APID
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Rapid traverse in JOG mode
32020
JOG_VELO
• Feed axis:
2,000
(mm/min)
• Spindle:
100 (rpm)
- DOUBLE mm/min, rpm RE
Jog axis velocity
32060
POS_AX_VEL
O
10,000
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Initial setting for positioning axis velocity
32100
AX_MOTION_D
IR
1 -1 to 1 DWORD - PO
Traversing direction (not control direction)
32110
ENC_FEEDBA
CK_POL[0]
1 -1 to 1 DWORD - PO
Sign actual value (control direction)
32200
POSCTRL_GAI
N[0] ... [5]
1.000000 0.000000 to
2000.000000
DOUBLE User defined CF
Servo gain factor
32250
RATED_OUTV
AL[0]
100 0.0 to 200 DOUBLE % CF
Rated output voltage
32260
RATED_VELO[
0]
2,000.0 - DOUBLE rpm CF
Rated motor speed
32300
MAX_AX_ACC
EL[0] ... [4]
•
Feed axis:
1.0
• Spindle:
– [0]...[2]:
10
– [3]...[4]:
2.778
≥ 0.001 DOUBLE mm/s
2
, rev/s
2
CF
Maximum axis acceleration
32450
Backlash[0]
0.0
-
DOUBLE
mm
CF
Backlash
32700
ENC_COMP_E
NABLE[0]
0 - BOOL - CF
Encoder/spindle error compensation
34000
REFP_CAM_IS
_ACTIVE
1 - BOOL - RE
Axis with reference point cam
