Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
399
No.
Name
Default
Range
Type
Unit
Activating
34010
REFP_CAM_DI
R_IS_MINUS
0 - BOOL - RE
Approach reference point in minus direction
34020
REFP_VELO_S
EARCH_CAM
5,000.0
(mm/min)
13.88 (rpm)
- DOUBLE mm/min, rpm RE
Reference point approach velocity
34040
REFP_VELO_S
EARCH_MARK
ER[0]
300.0 (mm/min)
0.833 (rpm)
- DOUBLE mm/min, rpm RE
Creep velocity
34050
REFP_SEARC
H_MARKER_R
EVERSE[0]
0 - BOOL - RE
Direction reversal to reference cam
34060
REFP_MAX_M
ARKER_DIST[0
]
20.0 - DOUBLE mm, degrees RE
Maximum distance to reference mark
34070
REFP_VELO_P
OS
10,000.00
(mm/min)
27.77 (rpm)
- DOUBLE mm/min, rpm RE
Reference point positioning velocity
34080
REFP_MOVE_
DIST[0]
-2.0 - DOUBLE mm, degrees RE
Reference point distance
34090
REFP_MOVE_
DIST_CORR[0]
0.0 - DOUBLE mm, degrees RE
Reference point offset/absolute offset
34092
REFP_CAM_S
HIFT
0.000000 - DOUBLE mm RE
Electronic cam offset for incremental measuring system
34093
REFP_CAM_M
ARKER_DIST[0
]
0 - DOUBLE mm PO
Reference cam/reference mark distance
34100
REFP_SET_PO
S[0] ... [3]
0.0 - DOUBLE mm, degrees RE
Reference point for incremental system
34200
ENC_REFP_M
ODE[0]
1 0 to 8 BYTE - PO
Referencing mode
34210
ENC_REFP_ST
ATE[0]
0 0 to 3 BYTE - IM
Adjustment status of the absolute encoder
34220
ENC_ABS_TU
RNS_MODULO
[0]
-1 1 to 100000 DWORD - PO
Modulo range for the rotary absolute encoder
