Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
400 6FC5397-4EP10-0BA8, 07/2018
No.
Name
Default
Range
Type
Unit
Activating
34230
ENC_SERIAL_
NUMBER[0]
0 - DWORD - PO
Encoder serial number
35010
GEAR_STEP_
CHANGE_ENA
BLE
0 - BOOL - RE
Parameterize gear stage change
35100 *
SPIND_VELO_
LIMIT
10,000.0 - DOUBLE rpm PO
Maximum spindle speed
35110
GEAR_STEP_
MAX_VELO[0]
... [5]
[0]...[1]: 500
[2]: 1,000
[3]: 2,000
[4]: 4,000
[5]: 8,000
- DOUBLE rpm CF
Maximum speed for gear stage change
35120
GEAR_STEP_
MIN_VELO[0]
... [5]
[0]...[1]: 50
[2]: 400
[3]: 800
[4]: 1,500
[5]: 3,000
- DOUBLE rpm CF
Minimum speed for gear stage change
35130
GEAR_STEP_
MAX_VELO_LI
MIT[0] ... [5]
[0]...[1]: 500
[2]: 1,000
[3]: 2,000
[4]: 4,000
[5]: 8,000
- DOUBLE rpm CF
Maximum speed for gear stage
35140
GEAR_STEP_
MIN_VELO_LI
MIT[0] ... [5]
[0]...[1]: 5
[2]: 10
[3]: 20
[4]: 40
[5]: 80
- DOUBLE rpm CF
Minimum speed for gear stage
36100
POS_LIMIT_MI
NUS
-100,000,000 - DOUBLE mm, degrees RE
1st software limit switch minus
Access level: Manufacturer
36110
POS_LIMIT_PL
US
100,000,000 - DOUBLE mm, degrees RE
1st software limit switch plus
36200
AX_VELO_LIMI
T[0] ... [5]
11,500
(mm/min)
31,944 (rpm)
- DOUBLE mm/min, rpm CF
Threshold value for velocity monitoring
36300
ENC_FREQ_LI
MIT[0]
3.33e5 - DOUBLE - PO
Encoder limit frequency
