Shaft height 65 mm, with straight connectors and the incremental encoder
Shaft height 65 mm, with angular connectors and the incremental encoder
Stall torque
k
k1
a
b
b1
4 Nm
148
202.5
163
15 69.5
6 Nm
181
1)
/164.5
2)
235.5
1)
/219
2)
196
1)
/179.5
2)
8 Nm
181
235.5
196
11 Nm
214
268.5
229
15 Nm
247
301.5
262
1)
For the motor variants with straight connectors;
2)
For the motor variants with angular connectors.
