Addr. Parameter C Setting Options Default Setting Comments
1518A 67 T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 67 Drop-Out Time Delay
1519A ROTATION ANGLE -180 .. 180 ° 45 ° Rotation Angle of Refer-
ence Voltage
1520A 67-2 MEASUREM. Fundamental
True RMS
Fundamental 67-2 measurement of
1521A 67-1 MEASUREM. Fundamental
True RMS
Fundamental 67-1 measurement of
1522A 67-TOC MEASUR. Fundamental
True RMS
Fundamental 67-TOC measurement of
1523 67-2 Direction Forward
Reverse
Non-Directional
Forward 67-2 Direction
1524 67-1 Direction Forward
Reverse
Non-Directional
Forward 67-1 Direction
1525 67-TOC Direct. Forward
Reverse
Non-Directional
Forward 67-TOC Direction
1526 67-3 Direction Forward
Reverse
Non-Directional
Forward 67-3 Direction
1527A 67-3 MEASUREM. Fundamental
True RMS
Fundamental 67-3 measurement of
1528 67-3 PICKUP 1A 1.00 .. 35.00 A; ∞ ∞ A 67-3 Pickup
5A 5.00 .. 175.00 A; ∞ ∞ A
1529 67-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67-3 Time Delay
1530 67 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
67
1531 MofPU Res T/Tp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> T/Tp
1532A 67-3 active always
with 79 active
always 67-3 active
1601 FCT 67N/67N-TOC OFF
ON
OFF 67N, 67N-TOC Ground
Time Overcurrent
1602 67N-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 0.50 A 67N-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
1603 67N-2 DELAY 0.00 .. 60.00 sec; ∞ 0.10 sec 67N-2 Time Delay
1604 67N-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 0.20 A 67N-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
1605 67N-1 DELAY 0.00 .. 60.00 sec; ∞ 0.50 sec 67N-1 Time Delay
1607 67N-TOC PICKUP 1A 0.05 .. 4.00 A 0.20 A 67N-TOC Pickup
5A 0.25 .. 20.00 A 1.00 A
1608 67N-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.20 sec 67N-TOC Time Dial
1609 67N-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67N-TOC Time Dial
1610 67N-TOC DropOut Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
Functions
2.3 Directional Overcurrent Protection 67, 67N
SIPROTEC 4, 7SJ62/64, Manual 107
C53000-G1140-C207-8, Edition 08.2016
