Addr. Parameter C Setting Options Default Setting Comments
3145 51Ns ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
3146 51Ns Drop-out Instantaneous
Disk Emulation
Disk Emulation Drop-out characteristic
3150 50Ns-2 Vmin 10.0 .. 90.0 V 10.0 V 50Ns-2 minimum voltage
3150 50Ns-2 Vmin 1.8 .. 50.0 V 2.0 V 50Ns-2 minimum voltage
3150 50Ns-2 Vmin 0.4 .. 50.0 V 2.0 V 50Ns-2 minimum voltage
3151 50Ns-2 Phi -180.0 .. 180.0 ° -90.0 ° 50Ns-2 angle phi
3152 50Ns-2 DeltaPhi 0.0 .. 180.0 ° 30.0 ° 50Ns-2 angle delta phi
3153 50Ns-1 Vmin 10.0 .. 90.0 V 15.0 V 50Ns-1 minimum voltage
3153 50Ns-1 Vmin 1.8 .. 50.0 V 6.0 V 50Ns-1 minimum voltage
3153 50Ns-1 Vmin 0.4 .. 50.0 V 6.0 V 50Ns-1 minimum voltage
3154 50Ns-1 Phi -180.0 .. 180.0 ° -160.0 ° 50Ns-1 angle phi
3155 50Ns-1 DeltaPhi 0.0 .. 180.0 ° 100.0 ° 50Ns-1 angle delta phi
3160 α1 red.dir.area 1 .. 15 ° 2 ° Alpha1 (reduction direc-
tional area)
3161 α2 red.dir.area 1 .. 15 ° 2 ° Alpha2 (reduction direc-
tional area)
Information List
No.
Information Type of
Informa-
tion
Comments
1201 >BLOCK 64 SP >BLOCK 64
1202 >BLOCK 50Ns-2 SP >BLOCK 50Ns-2
1203 >BLOCK 50Ns-1 SP >BLOCK 50Ns-1
1204 >BLOCK 51Ns SP >BLOCK 51Ns
1207 >BLK 50Ns/67Ns SP >BLOCK 50Ns/67Ns
1211 50Ns/67Ns OFF OUT 50Ns/67Ns is OFF
1212 50Ns/67Ns ACT OUT 50Ns/67Ns is ACTIVE
1215 64 Pickup OUT 64 displacement voltage pick up
1217 64 TRIP OUT 64 displacement voltage element TRIP
1221 50Ns-2 Pickup OUT 50Ns-2 Pickup
1223 50Ns-2 TRIP OUT 50Ns-2 TRIP
1224 50Ns-1 Pickup OUT 50Ns-1 Pickup
1226 50Ns-1 TRIP OUT 50Ns-1 TRIP
1227 51Ns Pickup OUT 51Ns picked up
1229 51Ns TRIP OUT 51Ns TRIP
1230 Sens. Gnd block OUT Sensitive ground fault detection BLOCKED
1264 IEEa = VI Corr. Resistive Earth current
1265 IEEr = VI Corr. Reactive Earth current
2.13.6
Functions
2.13 Ground Fault Protection 64, 67N(s), 50N(s), 51N(s)
SIPROTEC 4, 7SJ62/64, Manual 223
C53000-G1140-C207-8, Edition 08.2016
