Addr. Parameter C Setting Options Default Setting Comments
4008 46-TOC PICKUP 1A 0.05 .. 2.00 A 0.90 A 46-TOC Pickup
5A 0.25 .. 10.00 A 4.50 A
4009 46-TOC TIMEDIAL 0.50 .. 15.00 ; ∞ 5.00 46-TOC Time Dial
4010 46-TOC TIMEDIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 46-TOC Time Dial
4011 46-TOC RESET Instantaneous
Disk Emulation
Instantaneous 46-TOC Drop Out
4012A 46 T DROP-OUT 0.00 .. 60.00 sec 0.00 sec 46 Drop-Out Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
5143 >BLOCK 46 SP >BLOCK 46
5151 46 OFF OUT 46 switched OFF
5152 46 BLOCKED OUT 46 is BLOCKED
5153 46 ACTIVE OUT 46 is ACTIVE
5159 46-2 picked up OUT 46-2 picked up
5165 46-1 picked up OUT 46-1 picked up
5166 46-TOC pickedup OUT 46-TOC picked up
5170 46 TRIP OUT 46 TRIP
5171 46 Dsk pickedup OUT 46 Disk emulation picked up
2.7.5
Functions
2.7 Negative Sequence Protection 46
SIPROTEC 4, 7SJ62/64, Manual 143
C53000-G1140-C207-8, Edition 08.2016
