Parameters 6x54 dα SYNCHK α2>α1 and 6x55 dα SYNCHK α2<α1 confine the operating range for synchro-
nous switching. The availability of two parameters enables an asymmetrical release to be set.
Settings and Information
The following tables only list the settings and messages for function group 1. The settings and messages of
function groups 2 to 4 are the same type.
Settings
Addresses which have an appended “A” can only be changed with DIGSI, under “Additional Settings”.
Addr. Parameter Setting Options Default Setting Comments
6101 Synchronizing ON
OFF
OFF Synchronizing Function
6102 SyncCB (Einstellmöglichkeiten
anwendungsabhängig)
none Synchronizable circuit breaker
6103 Vmin 20 .. 125 V 90 V Minimum voltage limit: Vmin
6104 Vmax 20 .. 140 V 110 V Maximum voltage limit: Vmax
6105 V< 1 .. 60 V 5 V Threshold V1, V2 without voltage
6106 V> 20 .. 140 V 80 V Threshold V1, V2 with voltage
6107 SYNC V1<V2> YES
NO
NO ON-Command at V1< and V2>
6108 SYNC V1>V2< YES
NO
NO ON-Command at V1> and V2<
6109 SYNC V1<V2< YES
NO
NO ON-Command at V1< and V2<
6110A Direct CO YES
NO
NO Direct ON-Command
6111A TSUP VOLTAGE 0.00 .. 60.00 sec 0.10 sec Supervision time of V1>;V2> or
V1<;V2<
6112 T-SYN. DURATION 0.01 .. 1200.00 sec; ∞ 30.00 sec Maximum duration of Synchroni-
zation
6113A 25 Synchron YES
NO
YES Switching at synchronous condi-
tion
6120 T-CB close 0.01 .. 0.60 sec 0.06 sec Closing (operating) time of CB
6121 Balancing V1/V2 0.50 .. 2.00 1.00 Balancing factor V1/V2
6122A ANGLE ADJUSTM. 0 .. 360 ° 0 ° Angle adjustment (transformer)
6123 CONNECTIONof V2 A-G
B-G
C-G
A-B
B-C
C-A
A-B Connection of V2
6125 VT Vn2, primary 0.10 .. 800.00 kV 12.00 kV VT nominal voltage V2, primary
6130 dV ASYN V2>V1 0.5 .. 50.0 V 2.0 V Maximum voltage difference
V2>V1
6131 dV ASYN V2<V1 0.5 .. 50.0 V 2.0 V Maximum voltage difference
V2<V1
6132 df ASYN f2>f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2>f1
6133 df ASYN f2<f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2<f1
2.21.1.9
Functions
2.21 Synchronization Function
SIPROTEC 4, 7SJ62/64, Manual 303
C53000-G1140-C207-8, Edition 08.2016
