No. Information Type of
Informa-
tion
Comments
830 INs = MV INs Senstive Ground Fault Current
831 3Io = MV 3Io (zero sequence)
832 Vo = MV Vo (zero sequence)
901 PF = MV Power Factor
991 Press = MVU Pressure
992 Temp = MVU Temperature
996 Td1= MV Transducer 1
997 Td2= MV Transducer 2
1068 Θ RTD 1 = MV Temperature of RTD 1
1069 Θ RTD 2 = MV Temperature of RTD 2
1070 Θ RTD 3 = MV Temperature of RTD 3
1071 Θ RTD 4 = MV Temperature of RTD 4
1072 Θ RTD 5 = MV Temperature of RTD 5
1073 Θ RTD 6 = MV Temperature of RTD 6
1074 Θ RTD 7 = MV Temperature of RTD 7
1075 Θ RTD 8 = MV Temperature of RTD 8
1076 Θ RTD 9 = MV Temperature of RTD 9
1077 Θ RTD10 = MV Temperature of RTD10
1078 Θ RTD11 = MV Temperature of RTD11
1079 Θ RTD12 = MV Temperature of RTD12
16031 φ(3Vo,INs) = MV Angle between 3Vo and INsens.
16032 In2 = MV In2
30701 Pa = MV Pa (active power, phase A)
30702 Pb = MV Pb (active power, phase B)
30703 Pc = MV Pc (active power, phase C)
30704 Qa = MV Qa (reactive power, phase A)
30705 Qb = MV Qb (reactive power, phase B)
30706 Qc = MV Qc (reactive power, phase C)
30707 PFa = MV Power Factor, phase A
30708 PFb = MV Power Factor, phase B
30709 PFc = MV Power Factor, phase C
30800 VX = MV Voltage VX
Average Measurements
The long-term averages are calculated and output by the 7SJ62/64.
Description
Long-Term Averages
The long-term averages of the three phase currents Ι
x
, the positive sequence components Ι
1
for the three
phase currents, and the real power P, reactive power Q, and apparent power S are calculated within a set
period of time and indicated in primary values.
For the long-term averages mentioned above, the length of the time window for averaging and the frequency
with which it is updated can be set.
2.25.4
2.25.4.1
Functions
2.25 Auxiliary Functions
SIPROTEC 4, 7SJ62/64, Manual 333
C53000-G1140-C207-8, Edition 08.2016
