Protocol Transmittable measuring range, format
IEC 61850 The primary operational measured values are transmitted.
The measured values as well as their unit format are set out in detail in manual PIXIT
7SJ.
The measured values are transmitted in “Float” format. The transmitted measuring
range is not limited and corresponds to the operational measurement.
PROFIBUS, Modbus,
DNP 3.0
DNP3 TCP
PROFINET
The unit format of the measured values on the device side is at first automatically
generated by means of the selected nominal values of current and voltage within the
system data.
The current unit format can be determined in DIGSI or at the device via Menu Opera-
tional Values.
The user can select via DIGSI which operational measured values (primary, secondary
or percentage) must be transmitted.
The measured values are always transmitted as 16-bit values including sign (range ±
32768). The user can define the scaling of the operational measured value to be trans-
mitted. This will result in the respective transmittable measuring range.
For further details, please refer to the descriptions and protocol profiles.
Information List
No. Information Type of
Informa-
tion
Comments
268 Superv.Pressure OUT Supervision Pressure
269 Superv.Temp. OUT Supervision Temperature
601 Ia = MV Ia
602 Ib = MV Ib
603 Ic = MV Ic
604 In = MV In
605 I1 = MV I1 (positive sequence)
606 I2 = MV I2 (negative sequence)
621 Va = MV Va
622 Vb = MV Vb
623 Vc = MV Vc
624 Va-b= MV Va-b
625 Vb-c= MV Vb-c
626 Vc-a= MV Vc-a
627 VN = MV VN
629 V1 = MV V1 (positive sequence)
630 V2 = MV V2 (negative sequence)
632 Vsync = MV Vsync (synchronism)
641 P = MV P (active power)
642 Q = MV Q (reactive power)
644 Freq= MV Frequency
645 S = MV S (apparent power)
661 Θ REST. = MV Threshold of Restart Inhibit
701 INs Real MV Resistive ground current in isol systems
702 INs Reac MV Reactive ground current in isol systems
805 Θ Rotor MV Temperature of Rotor
807 Θ/Θtrip MV Thermal Overload
809 T reclose= MV Time untill release of reclose-blocking
2.25.3.3
Functions
2.25 Auxiliary Functions
332 SIPROTEC 4, 7SJ62/64, Manual
