Siemens SIPROTEC 4 - Mechanical Tests; Climatic Stress Tests

Harmonic currents on the network lead at AC 230 V
IEC 61000-3-2
Device is to be assigned Class D (applies only for devices
with > 50 VA power consumption)
Voltage fluctuations and flicker on the network lead
at AC 230 V
IEC 61000-3-3
Limits are observed
Mechanical Tests
Vibration and Shock Stress during Steady-State Operation
Standards: IEC 60255-21 and IEC 60068
Vibration
IEC 60255-21-1, Class 2;
IEC 60068-2-6
Sinusoidal
10 Hz to 60 Hz: ± 0.075 mm amplitude; 60 Hz to 150 Hz:
1g acceleration
frequency sweep rate 1 octave/min 20 cycles in 3
orthogonal axes
Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-27
Semi-sinusoidal
5 g acceleration, duration 11 ms, each 3 shocks in both
directions of the 3 axes
Seismic Vibration
IEC 60255-21-3, Class 1;
IEC 60068-3-3
Sinusoidal
1 Hz bis 8 Hz: ± 3.5 mm amplitude (horizontal axis)
1 Hz bis 8 Hz: ± 1.5 mm amplitude (vertical axis)
8 Hz bis 35 Hz: 1 g acceleration (horizontal axis)
8 Hz bis 35 Hz: 0,5 g acceleration (vertical axis)
Frequency sweep 1 octave/min,
1 cycle in 3 orthogonal axes
Vibration and Shock Stress during Transport
Standards:
IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2;
IEC 60068-2-6
Sinusoidal
5 Hz to 8 Hz: ±7.5 mm amplitude;
8 Hz to 150 Hz: 2 g acceleration
frequency sweep 1 octave/min
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-27
Semi-sinusoidal
15 g acceleration, duration 11 ms,
each 3 shocks (in both directions of the 3 axes)
Continuous Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-29
Semi-sinusoidal
10 g acceleration, duration 16 ms,
each 1000 shocks (in both directions of the 3 axes)
Climatic Stress Tests
Temperatures
1
)
Standards:
IEC 60255-6
Type tested (acc. IEC 60068-2-1 and -2, Test Bd, for
16 h)
–25 °C to +85 °C or –13 °F to +185 °F
4.1.6
4.1.7
Technical Data
4.1 General Device Data
SIPROTEC 4, 7SJ62/64, Manual 447
C53000-G1140-C207-8, Edition 08.2016
