Binary Output
Table E-4 Further Output Relay Presettings for all 7SJ62
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO3 52Breaker 52 Breaker
79 Close 2851 79 - Close command
Table E-5 Further Output Relay Presettings for 7SJ62
Binary Output Default function Function No. Description
BO4 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail V balance 167 Failure: Voltage Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
Fail Ph. Seq. V 176 Failure: Phase Sequence Voltage
BO7 Relay PICKUP 501 Relay PICKUP
Table E-6 Further Output Relay Presettings for 7SJ64
Binary Output Default function Function No. Description
BO3 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO4 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO5 52Breaker 52 Breaker
79 Close 2851 79 - Close command
Table E-7 Further Output Relay Presettings for 7SJ641/2/5/7
Binary Output Default function Function No. Description
BO1 GndSwit. Ground Switch
BO2 GndSwit. Ground Switch
BO10 Disc.Swit. Disconnect Switch
BO11 Disc.Swit. Disconnect Switch
E.3
Default Settings and Protocol-dependent Functions
E.3 Binary Output
602 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
