No. Information Type of
Informa-
tion
Comments
4602 >52-b SP >52-b contact (OPEN, if bkr is closed)
16019 >52 Wear start SP >52 Breaker Wear Start Criteria
16020 52 WearSet.fail OUT 52 Wear blocked by Time Setting Failure
16027 52WL.blk I PErr OUT 52 Breaker Wear Logic blk Ir-CB>=Isc-CB
16028 52WL.blk n PErr OUT 52 Breaker W.Log.blk SwCyc.Isc>=SwCyc.Ir
EN100-Module
Description
The Ethernet EN100-Modul enables integration of the 7SJ62/64 in 100-Mbit communication networks in
control and automation systems with the protocols according to IEC 61850 standard. This standard permits
uniform communication of the devices without gateways and protocol converters. Even when installed in
heterogeneous environments, SIPROTEC 4 relays therefore provide for open and interoperable operation.
Parallel to the process control integration of the device, this interface can also be used for communication
with DIGSI and for inter-relay communication via GOOSE.
Setting Notes
Interface Selection
No special settings are required for operating the Ethernet system interface module (IEC 1850, Ethernet
EN100-Modul). If the ordered version of the device is equipped with such a module, it is automatically allo-
cated to the interface available for it, namely Port B.
IEC 61850 GOOSE Function
The GOOSE function can be disabled via a device parameter. For more information, please refer to Section
2.1.2.2 Setting Notes.
Information List
No.
Information Type of
Informa-
tion
Comments
009.0100 Failure Modul IntSP Failure EN100 Modul
009.0101 Fail Ch1 IntSP Failure EN100 Link Channel 1 (Ch1)
009.0102 Fail Ch2 IntSP Failure EN100 Link Channel 2 (Ch2)
2.1.7
2.1.7.1
2.1.7.2
2.1.7.3
Functions
2.1 General
56 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
