Ethernet optical (EN100) for DIGSI, IEC61850, DNP3 TCP, PROFINET
Connection for Flush-mounted case rear panel, slot position “B”, duplex LC, 100BaseT acc. to IEEE802.3
Connection for Surface-mounted
case
not available
Transmission Speed 100 MBit/s
Optical wavelength 1300 nm
bridgeable distance max. 0.93 miles (1.5 km)
Time Synchronization Interface
Time Synchronization DCF 77 / IRIG B Signal
Connection for flush-mounted case Rear panel, mounting location “A”;
9-pin D-subminiature female connector
Connection for surface mounting
housing
at the double-deck terminal on the case bottom
Signal Nominal Voltages selectable 5 V, 12 V or 24 V
Test Voltage 500 V; 50 Hz
Signal Levels and Burdens
Nominal Signal Voltage
5 V 12 V 24 V
V
IHigh
6.0 V 15.8 V 31 V
V
ILow
1.0 V at Ι
ILow
= 0.25 mA 1.4 V at Ι
ILow
= 0.25 mA 1.9 V at Ι
ILow
= 0.25 mA
Ι
IHigh
4.5 mA to 9.4 mA 4.5 mA to 9.3 mA 4.5 mA to 8.7 mA
R
I
890 Ω at V
I
= 4 V 1930 Ω at V
I
= 8.7 V 3780 Ω at V
I
= 17 V
640 Ω at V
I
= 6 V 1700 Ω at V
I
= 15.8 V 3560 Ω at V
I
= 31 V
Electrical Tests
Regulations
Standards:
IEC 60255 (product standards)
ANSI/IEEE Std C37.90.0/.1/.2
UL 508
DIN 57435 Part 303
for more standards see also individual functions
Insulation Test
Standards:
IEC 60255-5 and IEC 60870-2-1
High Voltage Test (routine test) All circuits except
power supply, Binary Inputs, Communication Inter-
face and Time Synchronization Interfaces
2.5 kV (rms), 50 Hz
High voltage test (routine test). Auxiliary voltage
and binary inputs
3.5 kV–
High Voltage Test (routine test). Only Isolated
Communication and Time Synchronization Inter-
faces
500 V (rms), 50 Hz
4.1.5
Technical Data
4.1 General Device Data
SIPROTEC 4, 7SJ62/64, Manual 445
C53000-G1140-C207-8, Edition 08.2016
