Siemens SIPROTEC 4 User Manual

Protocol-dependent Functions
Protocol IEC
60870-5-10
3, single
IEC
60870-5-
103,
redun-
dant
IEC
61850
Ethernet
(EN 100)
PROFINET
Ethernet
(EN100)
Profibus
DP
Profibus
FMS
DNP 3 TCP
Ethernet
(EN100)
DNP3.0
Modbus
ASCII/RTU
Addi-
tional
service
interface
(optional
)
Function
Operational
Measured
Values
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Metered
values
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Fault
Recording
Yes Yes Yes No No. Only
via addi-
tional
service
interface
Yes Yes No. Only
via addi-
tional
service
interface
Yes
Remote relay
setting
No. Only via
additional
service inter-
face
Yes Yes No No. Only
via addi-
tional
service
interface
Yes No No. Only
via addi-
tional
service
interface
Yes
User-defined
messages and
switching
objects
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Time Synchro-
nization
Yes Yes Yes Yes Yes Yes Yes Yes —
Messages
with time
stamp
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Commissioning aids
Measured
value indica-
tion blocking
Yes Yes Yes No No Yes No No Yes
Creating test
messages
Yes Yes Yes No No Yes No No Yes
Physical mode Asynchro-
nous
Asyn-
chronous
Synchro-
nous
Synchro-
nous
Asyn-
chronous
Asyn-
chro-
nous
Synchro-
nous
Asynchro-
nous
—
Transmission
Mode
cyclically/
Event
cyclically/
Event
cyclically/
Event
cyclically cyclically cycli-
cally/
Event
cyclically/
Event
cyclically/
Event
(DNP)
cycli-
cally
(Modbu
s)
—
Baud rate 1200 to
115200
2400 to
57600
up to
100
MBaud
up to 100
MBaud
up to 1,5
MBaud
(optical
fiber)
6 MBaud
(RS485)
up to
1,5
MBaud
up to 100
MBaud
9600 to
57600
(DNP
)
300 to
57600
(Mod
bus)
4800 to
115200
E.7
Default Settings and Protocol-dependent Functions
E.7 Protocol-dependent Functions
SIPROTEC 4, 7SJ62/64, Manual 611
C53000-G1140-C207-8, Edition 08.2016
