Addr. Parameter C Setting Options Default Setting Comments
4207A Kτ-FACTOR 1.0 .. 10.0 1.0 Kt-FACTOR when motor
stops
4208A T EMERGENCY 10 .. 15000 sec 100 sec Emergency time
4209 49 TEMP. RISE I 40 .. 200 °C 100 °C 49 Temperature rise at
rated sec. curr.
4210 49 TEMP. RISE I 104 .. 392 °F 212 °F 49 Temperature rise at
rated sec. curr.
4211 TEMPSENSOR RTD 1 .. 6 1 Temperature sensor
connected to RTD
4212 TEMPSENSOR RTD 1 .. 12 1 Temperature sensor
connected to RTD
Information List
No. Information Type of
Informa-
tion
Comments
1503 >BLOCK 49 O/L SP >BLOCK 49 Overload Protection
1507 >EmergencyStart SP >Emergency start of motors
1511 49 O / L OFF OUT 49 Overload Protection is OFF
1512 49 O/L BLOCK OUT 49 Overload Protection is BLOCKED
1513 49 O/L ACTIVE OUT 49 Overload Protection is ACTIVE
1515 49 O/L I Alarm OUT 49 Overload Current Alarm (I alarm)
1516 49 O/L Θ Alarm OUT 49 Overload Alarm! Near Thermal Trip
1517 49 Winding O/L OUT 49 Winding Overload
1521 49 Th O/L TRIP OUT 49 Thermal Overload TRIP
1580 >RES 49 Image SP >49 Reset of Thermal Overload Image
1581 49 Image res. OUT 49 Thermal Overload Image reset
2.11.4
Functions
2.11 Thermal Overload Protection 49
SIPROTEC 4, 7SJ62/64, Manual 179
C53000-G1140-C207-8, Edition 08.2016
