Ordering Information 7SJ64 V4.9
Multi-Functional
Protective Relay with
Local Control
6 7 8 9 10 11 12 13 14 15 16 Zusatz
7 S J 6 4 – – +
Housing, Inputs and Outputs, Measuring Transducer Pos. 6
Housing
1
/
3
19”, 4-line Display, 7 BI, 5 BO, 1 Live Status Contact; 9th position only with: B, D, E
0
Housing
1
/
2
19”, Graphic Display, 15 BI, 13 BO, 1 Live Status Contact
1
Housing
1
/
2
19”, Graphic Display, 20 BI, 8 BO, 2 High-duty relays (4 Contacts), 1 Live Status Contact
2
Housing
1
/
1
19”, Graphic Display, 33 BI, 11 BO, 4 High-duty relays (8 Contacts), 1 Live Status Contact
5
Housing
1
/
1
19”, Graphic Display, 48 BI, 21 BO, 4 High-duty relays (8 Contacts), 1 Live Status Contact
7
Measuring Inputs (4 x V, 4 x Ι)
Pos. 7
Ι
N
= 1 A, Ι
e
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G
1
Ι
N
= 1 A, Ι
e
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H
2
Ι
N
= 5 A, Ι
e
= 5 A (min. = 0.25 A); 15th position only with A, C, E, G
5
Ι
N
= 5 A, Ι
e
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H
6
Ι
N
= 5 A, Ι
e
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G
7
Power Supply, Binary Input Pickup Threshold Setting Pos. 8
DC 24 to 48 V, Binary Input Threshold DC 19 V 2
DC 60 to 125 V, Binary Input Threshold DC 19 V 4
DC 110 to 250 V, AC 115 to 230 V
1)
, Binary Input Threshold DC 88 V
5
1)
AC 230 V only possible with release 7SJ64**...../CC and higher
Construction
Pos. 9
Surface-mounting case, plug-in terminals, detached operator panel Installation in a low-voltage compartment A
Surface-mounting case for panel, 2 tier terminals top/bottom B
Surface-mounting case, screw-type terminals (direct connection / ring and spade lugs), detached operator
panel, installation in a low-voltage
C
Flush mounting case with plug-in terminals (2/3 pin connector) D
Flush mounting case, screw-type terminals (direct connection / ring and spade lugs) E
Surface-mounting case, screw-type terminals (direct connection / ring and spade lugs), without operator
panel, installation in a low-voltage
F
Surface-mounting case, plug-in terminals, without operator panel Installation in a low-voltage compartment G
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, Language German (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, language English (language can be changed) B
Region US, 60 Hz, ANSI/IEC, Language American English (Language can be changed) C
Region FR, 50/60 Hz, IEC/ANSI, Language French (Language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, Language Spanish (Language can be changed) E
Region World, 50/60 Hz, IEC/ANSI, Language Italian (Language can be changed) F
Region World, 50/60 Hz, IEC/ANSI, Language Russian (Language can be changed) G
System Interface (Rear Side, Port B) Pos. 11
No system interface 0
IEC 60870-5-103 Protocol, electrical RS232 1
A.2
Ordering Information and Accessories
A.2 Ordering Information 7SJ64 V4.9
SIPROTEC 4, 7SJ62/64, Manual 531
C53000-G1140-C207-8, Edition 08.2016
