System Interface (Rear Side, Port B) Pos. 11
IEC 60870-5-103 Protocol, electrical RS485 2
IEC 60870-5-103 Protocol, optical 820 nm, ST-connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, optical, Single Ring, ST-connector
1)
5
1)
Profibus FMS Slave, optical, Double Ring, ST-connector
1)
6
1)
For further interface options see Additional Information in the following L 9
Additional information L to further system interfaces (device rear, port B) Supple-
mentary
Profibus DP Slave, RS485 + L 0 A
Profibus DP Slave, 820 nm, optical double ring, ST-connector
1)
+ L 0 B
1)
Modbus RS 485 + L 0 D
Modbus, 820 nm, optical, ST-connector
3)
+ L 0 E
3)
DNP3.0, RS 485 + L 0 G
DNP3.0, 820 nm, optical, ST-connector
3)
+ L 0 H
3)
IEC 60870-5-103 protocol, redundant, electrical RS485, RJ45-connector
3)
+ L 0 P
IEC 61850, Ethernet electrical, double, RJ45-connector (EN 100) + L 0 R
IEC 61850, Ethernet optical, double, duplex LC-connector (EN 100)
3)
+ L 0 S
3)
DNP3 TCP über IP, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100) + L 2 R
DNP3 TCP über IP, 100 Mbit Ethernet optical, double, duplex LC connector (EN 100)
3)
+ L 2 S
3)
PROFINET über IP, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100) + L 3 R
PROFINET über IP, 100 Mbit Ethernet optical, double, duplex LC connector (EN 100)
+ L 3 S
3)
1)
Cannot be delivered in connection with 9th digit = "B". If the optical interface is required you must order the
following: 11. digit = 4 (RS485) and in addition, the associated converter.
2)
Cannot be delivered in connection with 9th digit = "B".
Converter
Order No. Use
SIEMENS OLM
1)
6GK1502–2CB10 For single ring
SIEMENS OLM
1)
6GK1502–3CB10 For double ring
1)
The converter requires an operating voltage of 24 VDC. If the available operating voltage is > 24 VDC the
additional power supply 7XV5810–0BA00 is required.
DIGSI/Modem Interface (Rear Side, Port C)
Pos. 12
DIGSI/Modem, electrical RS232 1
DIGSI/Modem/RTD box
1)
, electrical RS485
2
For further interface options see Additional Information M 9
1)
RTD-box 7XV5662–6AD10
Additional Information M, Service and Additional Interface (Port C and Port D)
Port C: DIGSI/Modem, electrical RS232 M 1 *
Port C: DIGSI/Modem/RTD box
1)
, electrical RS485
M 2 *
Port D: RTD box
1)
, optical 820 nm
2)
, ST connector
M * A
Port D: RTD box
1)
, electrical RS485
M * F
1)
RTD box 7XV5662–6AD10
2)
If you want to run the RTD box on an optical port, you will also need the RS485 optical converter 7XV5650–
0*A00.
Ordering Information and Accessories
A.2 Ordering Information 7SJ64 V4.9
532 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
