Ordering Information 7SJ62 V4.9
Multi-Functional
Protective Relay with
Local Control
6 7 8 9 10 11 12 13 14 15 16 Zusatz
7 S J 6 2 – – +
Number of Inputs and Outputs Pos. 6
Housing
1
/
3
19”, 4-line display, 3 x V, 4 x Ι, 8 BI, 8 BO, 1 life contact
1
Housing
1
/
3
19”, 4-line display, 3 x V, 4 x Ι, 11 BI, 6 BO, 1 life contact
2
Housing
1
/
3
19”, 4-line display, 4 x V, 4 x Ι, 8 BI, 8 BO, 1 life contact
3
Housing
1
/
3
19”, 4-line display, 4 x V, 4 x Ι, 11 BI, 6 BO, 1 life contact
4
Housing
1
/
2
19”, Grafikdisplay, 4 x V, 4 x Ι, 8 BI, 8 BO, 1 life contact
5
Housing
1
/
2
19”, Grafikdisplay, 4 x V, 4 x Ι, 11 BI, 6 BO, 1 life contact
6
Measuring Inputs (3 x V, 4 x Ι)
Pos. 7
Ι
N
= 1 A, Ι
e
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G
1
Ι
N
= 1 A, Ι
e
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H
2
Ι
N
= 5 A, Ι
e
= 5 A (min. = 0.25 A); 15th position only with A, C, E, G
5
Ι
N
= 5 A, Ι
e
= sensitive (min. = 0.001 A); 15th position only with B, D, F, H
6
Ι
N
= 5 A, Ι
e
= 1 A (min. = 0.05 A); 15th position only with A, C, E, G
7
Power Supply, Binary Input Pickup Threshold Setting Pos. 8
DC 24 to 48 V, Binary Input Threshold 19 DC 19 V 2
DC 60 to 125 V, Binary Input Threshold 19 DC 19 V 4
DC 110 to 250 V, AC 115 V to 230 V, Binary Input Threshold 19 DC 88 V 5
DC 110 to 250 V, AC 115 V to 230 V, Binary Input Threshold 19 DC 176 V 6
Construction Pos. 9
Surface-mounting case for panel, 2 tier terminals top/bottom B
Flush mounting case with plug-in terminals (2/3 pin connector) D
Flush mounting case, screw-type terminals (direct connection / ring and spade lugs) E
Region-specific Default / Language Settings and Function Versions Pos. 10
Region DE, 50 Hz, IEC, Language German (Language can be changed) A
Region US, 60 Hz, ANSI/IEC, Language American English (Language can be changed) B
Region US, 60 Hz, ANSI/IEC, Language American English (Language can be changed) C
Region FR, 50/60 Hz, IEC/ANSI, Language French (Language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, Language Spanish (Language can be changed) E
Region World, 50/60 Hz, IEC/ANSI, Language Italian (Language can be changed) F
Region World, 50/60 Hz, IEC/ANSI, Language Russian (Language can be changed) G
System Interface (Rear Side, Port B) Pos. 11
No system interface 0
IEC 60870-5-103 Protocol, electrical RS232 1
IEC 60870-5-103 Protocol, electrical RS485 2
IEC 60870-5-103 Protocol, optical 820 nm, ST-connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS Slave, optical, Single Ring, ST-Connector
1)
5
1)
A.1
Ordering Information and Accessories
A.1 Ordering Information 7SJ62 V4.9
526 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
