System Interface (Rear Side, Port B) Pos. 11
Profibus FMS Slave, optical, Double Ring, ST-Connector
1)
6
1)
For further interface options see Additional Information in the following 9
Additional information to further system interfaces (device rear, port B) Supple-
mentary
Profibus DP Slave, RS485 + L 0 A
Profibus DP Slave, 820 nm, optical Double Ring, ST-connector
1)
+ L 0 B
1)
Modbus RS 485 + L 0 D
Modbus, 820 nm, optical, ST-connector
3)
+ L 0 E
3)
DNP3.0, RS 485 + L 0 G
DNP3.0, 820 nm, optical, ST-connector
3)
+ L 0 H
3)
IEC 60870-5-103 Protocol, redundant, electrical RS485, RJ45-connector
3)
+ L 0 P
3)
IEC 61850, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100) + L 0 R
IEC 61850, 100 Mbit Ethernet optical, double, duplex LC connector (EN 100)
3)
+ L 0 S
3)
DNP3 TCP über IP, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100) + L 2 R
DNP3 TCP über IP, 100 Mbit Ethernet optical, double, duplex LC connector (EN 100)
3)
+ L 2 S
3)
PROFINET over IP, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100) + L 3 R
PROFINET over IP, 100 Mbit Ethernet electrical, double, RJ45 connector (EN 100)
3)
+ L3 S
3)
1)
Cannot be delivered in connection with 9th digit = "B". If the optical interface is required you must order the
following: 11th digit = 4 (RS485) and in addition, the associated converter
2)
Cannot be delivered in connection with 9th digit = "B".
Converter
Order No. Use
SIEMENS OLM
1)
6GK1502–2CB10 For single ring
SIEMENS OLM
1)
6GK1502–3CB10 For double ring
1)
The converter requires an operating voltage of 24 VDC. If the available operating voltage is > 24 VDC the
additional power supply 7XV5810–0BA00 is required.
DIGSI/Modem Interface (Rear Side, Port C)
Pos. 12
No DIGSI interface at the back 0
DIGSI/Modem, electrical RS232 1
DIGSI/Modem/RTD box
1)
, electrical RS485
2
DIGSI/Modem/RTD box
1)
, optical 820 nm, ST connector
2)
3
1)
RTD-box 7XV5662–6AD10
2)
If you want to run the RTD-Box at an optical interface, you need also the RS485–FO–converter 7XV5650–
0*A00.
Measuring/Fault Recording
Pos. 13
With fault recording 1
With fault recording, average values, min/max values 3
Functions Pos. 14
and 15
Designation ANSI-No. Description
Basic Elements (included in all
versions)
— Control
50/51 Time overcurrent protection phase 50-1, 50-2, 50-3, 51
50N/51N Time overcurrent protection ground 50N-1, 50N-2,
50N-3, 51N
Ordering Information and Accessories
A.1 Ordering Information 7SJ62 V4.9
SIPROTEC 4, 7SJ62/64, Manual 527
C53000-G1140-C207-8, Edition 08.2016
