No. Information Type of
Informa-
tion
Comments
1022 Σ Ib = VI Accumulation of interrupted current Ph B
1023 Σ Ic = VI Accumulation of interrupted current Ph C
2896 79 #Close1./3p= VI No. of 1st AR-cycle CLOSE commands,3pole
2898 79 #Close2./3p= VI No. of higher AR-cycle CLOSE commands,3p
16001 ΣI^x A= VI Sum Current Exponentiation Ph A to Ir^x
16002 ΣI^x B= VI Sum Current Exponentiation Ph B to Ir^x
16003 ΣI^x C= VI Sum Current Exponentiation Ph C to Ir^x
16006 Resid.Endu. A= VI Residual Endurance Phase A
16007 Resid.Endu. B= VI Residual Endurance Phase B
16008 Resid.Endu. C= VI Residual Endurance Phase C
16011 mechan.TRIP A= VI Number of mechanical Trips Phase A
16012 mechan.TRIP B= VI Number of mechanical Trips Phase B
16013 mechan.TRIP C= VI Number of mechanical Trips Phase C
16014 ΣI^2t A= VI Sum Squared Current Integral Phase A
16015 ΣI^2t B= VI Sum Squared Current Integral Phase B
16016 ΣI^2t C= VI Sum Squared Current Integral Phase C
Information List
No.
Information Type of
Informa-
tion
Comments
10027 StartDuration1 VI Startup Duration 1
10028 StartupCurrent1 VI Startup Current 1
10029 StartupVoltage1 VI Startup Voltage 1
10030 Nr.of Mot.Start VI Total Number of Motor Starts
10031 Motor Run.Time VI Total Motor Running Time
10032 Motor Stop.Time VI Total Motor Stopped Time
10033 Perc.Run.Time VI Motor Percent Running Time
10037 StartDuration2 VI Startup Duration 2
10038 StartupCurrent2 VI Startup Current 2
10039 StartupVoltage2 VI Startup Voltage 2
10040 StartDuration3 VI Startup Duration 3
10041 StartupCurrent3 VI Startup Current 3
10042 StartupVoltage3 VI Startup Voltage 3
10043 StartDuration4 VI Startup Duration 4
10044 StartupCurrent4 VI Startup Current 4
10045 StartupVoltage4 VI Startup Voltage 4
10046 StartDuration5 VI Startup Duration 5
10047 StartupCurrent5 VI Startup Current 5
10048 StartupVoltage5 VI Startup Voltage 5
Measurement
A series of measured values and the values derived from them are constantly available for call up on site, or
for data transfer.
