Initiation of Measurement
Normally the fault location calculation is started when a directional or non-directional time overcurrent protec-
tion initiates a trip signal (address 8001 START = TRIP). However, it may also be initiated when pickup drops
out (address 8001 START = Pickup), e.g. when another protection element clears the fault. Irrespective of
this fact, calculation of the fault location can be triggered externally via a binary input. (FNo. 1106
>Start
Flt. Loc
) provided the device has picked up.
Settings
Addr. Parameter Setting Options Default Setting Comments
8001 START Pickup
TRIP
Pickup Start fault locator with
Information List
No. Information Type of
Informa-
tion
Comments
1106 >Start Flt. Loc SP >Start Fault Locator
1114 Rpri = VI Flt Locator: primary RESISTANCE
1115 Xpri = VI Flt Locator: primary REACTANCE
1117 Rsec = VI Flt Locator: secondary RESISTANCE
1118 Xsec = VI Flt Locator: secondary REACTANCE
1119 dist = VI Flt Locator: Distance to fault
1120 d[%] = VI Flt Locator: Distance [%] to fault
1122 dist = VI Flt Locator: Distance to fault
1123 FL Loop AG OUT Fault Locator Loop AG
1124 FL Loop BG OUT Fault Locator Loop BG
1125 FL Loop CG OUT Fault Locator Loop CG
1126 FL Loop AB OUT Fault Locator Loop AB
1127 FL Loop BC OUT Fault Locator Loop BC
1128 FL Loop CA OUT Fault Locator Loop CA
1132 Flt.Loc.invalid OUT Fault location invalid
2.17.3
2.17.4
Functions
2.17 Fault Locator
262 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
