UL–listed with the Following Nominal Values:
240 Vac 5 A General Purpose
24 Vdc 5 A General Purpose
48 Vdc 0.8 A General Purpose
240 Vdc 0.1 A General Purpose
120 Vac
1/6 hp (4.4 FLA
1)
)
240 Vac
1/2 hp (4.9 FLA
1)
)
**)
UL–listed with the Following Nominal Values:
240 Vdc
1.6 FLA
1)
120 Vdc
3.2 FLA
1)
60 Vdc
5.5 FLA
1)
1)
FLA = “Full Load Ampere”
2)
High-duty relays are used for the direct activation of motor-driven switches. The high-duty relays operate in
an interlocked mode, i.e. only one binary output of each pair of switches is activated, thus avoiding a short-
circuit of the power supply. When used as a standard relay, only one binary output of a pair can be used.
Permanent operation is not specified.
Communication Interfaces
User Interface
Connection
front side, non-isolated, RS232, 9 pole DSUB port for connecting a
personal computer
(PELV)
Operation With DIGSI
Transmission speed min. 4,800 Bd; max. 115,200 Bd;
Factory Setting: 115,200 Baud; Parity: 8E1
Bridgeable distance 15 m
Service/Modem Interface
Connection
isolated interface for data transfer
Operation With DIGSI
Transmission Speed min. 4,800 baud, max. 115,200 baud; Factory setting 38,400 Baud
RS232/RS485/FO according to the ordering variant
RS232/RS485
Connection for flush-mounted
casing
rear panel, mounting location “C”,
9-pole D-SUB miniature female connector
Connection for surface-mounted
casing
at the housing mounted case on the case bottom; shielded data cable
Test Voltage (PELV) 500 V; 50 Hz
RS232 Maximum Distance of Trans-
mission
15 m
RS485 Maximum Distance of Trans-
mission
1000 m
Fiber Optical Link (FO)
1)
FO connector type ST connector
4.1.4
Technical Data
4.1 General Device Data
SIPROTEC 4, 7SJ62/64, Manual 441
C53000-G1140-C207-8, Edition 08.2016
