Addr. Parameter C Setting Options Default Setting Comments
1631 I/IEp Rf T/TEp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
67N TOC
1632A 67N-3 active always
with 79 active
always 67N-3 active
Information List
No. Information Type of
Informa-
tion
Comments
2603 67N-3 TRIP OUT 67N-3 TRIP
2604 >BLK 67/67-TOC SP >BLOCK 67/67-TOC
2605 67N-3 BLOCKED OUT 67N-3 is BLOCKED
2606 67-3 BLOCKED OUT 67-3 is BLOCKED
2614 >BLK 67N/67NTOC SP >BLOCK 67N/67N-TOC
2615 >BLOCK 67-2 SP >BLOCK 67-2
2616 >BLOCK 67N-2 SP >BLOCK 67N-2
2617 >BLOCK 67-3 SP >BLOCK 67-3
2618 >BLOCK 67N-3 SP >BLOCK 67N-3
2621 >BLOCK 67-1 SP >BLOCK 67-1
2622 >BLOCK 67-TOC SP >BLOCK 67-TOC
2623 >BLOCK 67N-1 SP >BLOCK 67N-1
2624 >BLOCK 67N-TOC SP >BLOCK 67N-TOC
2628 Phase A forward OUT Phase A forward
2629 Phase B forward OUT Phase B forward
2630 Phase C forward OUT Phase C forward
2632 Phase A reverse OUT Phase A reverse
2633 Phase B reverse OUT Phase B reverse
2634 Phase C reverse OUT Phase C reverse
2635 Ground forward OUT Ground forward
2636 Ground reverse OUT Ground reverse
2637 67-1 BLOCKED OUT 67-1 is BLOCKED
2642 67-2 picked up OUT 67-2 picked up
2646 67N-2 picked up OUT 67N-2 picked up
2647 67-2 Time Out OUT 67-2 Time Out
2648 67N-2 Time Out OUT 67N-2 Time Out
2649 67-2 TRIP OUT 67-2 TRIP
2651 67/67-TOC OFF OUT 67/67-TOC switched OFF
2652 67 BLOCKED OUT 67/67-TOC is BLOCKED
2653 67 ACTIVE OUT 67/67-TOC is ACTIVE
2655 67-2 BLOCKED OUT 67-2 is BLOCKED
2656 67N OFF OUT 67N/67N-TOC switched OFF
2657 67N BLOCKED OUT 67N/67N-TOC is BLOCKED
2658 67N ACTIVE OUT 67N/67N-TOC is ACTIVE
2659 67N-1 BLOCKED OUT 67N-1 is BLOCKED
2660 67-1 picked up OUT 67-1 picked up
2664 67-1 Time Out OUT 67-1 Time Out
2.3.12
Functions
2.3 Directional Overcurrent Protection 67, 67N
SIPROTEC 4, 7SJ62/64, Manual 109
C53000-G1140-C207-8, Edition 08.2016
