No. Information Type of
Informa-
tion
Comments
2665 67-1 TRIP OUT 67-1 TRIP
2668 67N-2 BLOCKED OUT 67N-2 is BLOCKED
2669 67-TOC BLOCKED OUT 67-TOC is BLOCKED
2670 67-TOC pickedup OUT 67-TOC picked up
2674 67-TOC Time Out OUT 67-TOC Time Out
2675 67-TOC TRIP OUT 67-TOC TRIP
2676 67-TOC DiskPU OUT 67-TOC disk emulation is ACTIVE
2677 67N-TOC BLOCKED OUT 67N-TOC is BLOCKED
2678 67-3 TRIP OUT 67-3 TRIP
2679 67N-2 TRIP OUT 67N-2 TRIP
2681 67N-1 picked up OUT 67N-1 picked up
2682 67N-1 Time Out OUT 67N-1 Time Out
2683 67N-1 TRIP OUT 67N-1 TRIP
2684 67N-TOCPickedup OUT 67N-TOC picked up
2685 67N-TOC TimeOut OUT 67N-TOC Time Out
2686 67N-TOC TRIP OUT 67N-TOC TRIP
2687 67N-TOC Disk PU OUT 67N-TOC disk emulation is ACTIVE
2691 67/67N pickedup OUT 67/67N picked up
2692 67 A picked up OUT 67/67-TOC Phase A picked up
2693 67 B picked up OUT 67/67-TOC Phase B picked up
2694 67 C picked up OUT 67/67-TOC Phase C picked up
2695 67N picked up OUT 67N/67N-TOC picked up
2696 67/67N TRIP OUT 67/67N TRIP
2697 67-3 picked up OUT 67-3 picked up
2698 67N-3 picked up OUT 67N-3 picked up
2699 67-3 Time Out OUT 67-3 Time Out
2700 67N-3 Time Out OUT 67N-3 Time Out
14513 >INSTANT. 67-3 SP >67-3 instantaneously
14514 67-3 INSTANT. OUT 67-3 instantaneously
14515 >INSTANT. 67N-3 SP >67N-3 instantaneously
14516 67N-3 INSTANT. OUT 67N-3 instantaneously
Functions
2.3 Directional Overcurrent Protection 67, 67N
