Addr. Parameter C Setting Options Default Setting Comments
2101 67Nc-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 7.00 A 67Nc-2 Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
2102 67Nc-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67Nc-2 Time Delay
2103 67Nc-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 1.50 A 67Nc-1 Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
2104 67Nc-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 67Nc-1 Time Delay
2105 67Nc-TOC PICKUP 1A 0.05 .. 4.00 A 1.00 A 67Nc-TOC Pickup
5A 0.25 .. 20.00 A 5.00 A
2106 67Nc-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 67Nc-TOC Time Dial
2107 67Nc-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67Nc-TOC Time Dial
2108 67Nc-3 PICKUP 0.25 .. 35.00 A; ∞ ∞ A 67Nc-3 Pickup
2109 67Nc-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67Nc-3 Time Delay
Information List
No. Information Type of
Informa-
tion
Comments
1730 >BLOCK CLP SP >BLOCK Cold-Load-Pickup
1731 >BLK CLP stpTim SP >BLOCK Cold-Load-Pickup stop timer
1732 >ACTIVATE CLP SP >ACTIVATE Cold-Load-Pickup
1994 CLP OFF OUT Cold-Load-Pickup switched OFF
1995 CLP BLOCKED OUT Cold-Load-Pickup is BLOCKED
1996 CLP running OUT Cold-Load-Pickup is RUNNING
1997 Dyn set. ACTIVE OUT Dynamic settings are ACTIVE
2.4.4
Functions
2.4 Dynamic Cold Load Pickup
116 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
