Page #224 background image
No. Information Type of
Informa-
tion
Comments
1266 IEE = VI Earth current, absolute Value
1267 VGND, 3Vo VI Displacement Voltage VGND, 3Vo
1271 Sens.Gnd Pickup OUT Sensitive Ground fault pick up
1272 Sens. Gnd Ph A OUT Sensitive Ground fault picked up in Ph A
1273 Sens. Gnd Ph B OUT Sensitive Ground fault picked up in Ph B
1274 Sens. Gnd Ph C OUT Sensitive Ground fault picked up in Ph C
1276 SensGnd Forward OUT Sensitive Gnd fault in forward direction
1277 SensGnd Reverse OUT Sensitive Gnd fault in reverse direction
1278 SensGnd undef. OUT Sensitive Gnd fault direction undefined
16029 51Ns BLK PaErr OUT Sens.gnd.flt. 51Ns BLOCKED Setting Error
16030 φ(3Vo,INs) = VI Angle between 3Vo and INsens.
16034 50Ns-1n.TRrange OUT 50Ns-1 not in tripping range
16035 50Ns-2n.TRrange OUT 50Ns-2 not in tripping range
Functions
2.13 Ground Fault Protection 64, 67N(s), 50N(s), 51N(s)
224 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
