Pickup Voltage of BI4 to BI11
Table 3-11 Jumper settings for pickup voltages of binary inputs BI4 to BI11 on the input/output board A–
I/O-2 as from 7SJ62.../FFBrückenstellung der Steuerspannungen der Binäreingänge BE4 bis
BE11 auf der Ein-/Ausgabebaugruppe A-I/O-2 ab 7SJ62.../FF
Binary inputs Jumper DC 19 V threshold
1)
DC 88 V threshold
3)
DC 176 V threshold
BI4 X21 L M H
BI5 X22 L M H
BI6 X23 L M H
BI7 X24 L M H
BI8 X25 L M H
BI9 X26 L M H
BI10 X27 L M H
BI11 X28 L M H
1)
Factory settings for devices with power supply voltages of DC 24 V to 125 V
2)
Factory settings for devices with power supply voltages of DC 110 V to 220 V and AC 115 V/ 230 V
Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC 4, 7SJ62/64, Manual 387
C53000-G1140-C207-8, Edition 08.2016
