Dimensions see dimensional drawings, Section 4.29 Dimensions
Variant Case Size Weight
(mass)
7SJ621/2/3/4*-*B in surface mounting housing
1
/
3
8.8 lb or 4.5
kg
7SJ621/2/3/4*-*D/E in flush mounting housing
1
/
3
8.8 lb or 4 kg
7SJ625/6*-*B for panel surface mounting
1
/
2
7.5 kg
7SJ625/6*-*D/E for panel flush mounting
1
/
2
6,5 kg
7SJ640*-*B in surface mounting housing
1
/
3
17.4 lb or 8 kg
7SJ641/2*-*B in surface mounting housing
1
/
2
24.25 lb or 11
kg
7SJ645*-*B in surface mounting housing
1
/
1
33.07 lb or 15
kg
7SJ641/2*-*A/C in housing for detached operator panel
1
/
2
17.4 lb or 8 kg
7SJ645*-*A/C in housing for detached operator panel
1
/
1
26.45 lb or 12
kg
7SJ647*-*A/C for mounting with detached operator panel
1
/
1
12.5 kg
7SJ641/2*-*F/G in housing without operator panel
1
/
2
17.4 lb or 8 kg
7SJ645*-*F/G in housing without operator panel
1
/
1
26.45 lb or 12
kg
7SJ647*-*F/G for housing without operator panel
1
/
1
12.5 kg
7SJ640*-*D/E in flush mounting housing
1
/
3
11.02 lb or 5
kg
7SJ641/2*-*D/E in flush mounting housing
1
/
2
13.23 lb or 6
kg
7SJ645*-*D/E in flush mounting housing
1
/
1
22.05 lb or 10
kg
7SJ647*-*D/E for panel surface mounting
1
/
1
10.5 kg
Detached operator panel 5.51 lb or 2.5
kg
International Protection Under IEC 60529
for equipment of the surface mounting housing IP 51
in flush mounted case and in model with detached
operator panel
Front IP 51
Rear IP 50
For personal protection IP 2x with cover cap
UL-certification conditions “For use on a Flat Surface of a Type 1 Enclosure”
Technical Data
4.1 General Device Data
SIPROTEC 4, 7SJ62/64, Manual 449
C53000-G1140-C207-8, Edition 08.2016
