3-pin C73334-A1-C36-1
Mounting Rail for 19"-Racks
Name Order No.
Angle Strip (Mounting Rail) C73165-A63-C200-4
Battery
Lithium battery 3 V/1 Ah, type CR 1/2 AA Order No.
VARTA 6127 101 301
Panasonic BR-1/2AA
Interface Cable
Interface cable between PC or SIPROTEC device Order No.
Cable with 9-pin male/female connections 7XV5100-4
Varistor
Voltage-limiting resistor for high-impedance differential protection
Name Order number
125 Veff, 600 A, 1S/S256 W73028-V3125-A1
240 Veff, 600 A, 1S/S1088 W73028-V3300-A2
Dongle Cable
Name
Order Number
Cable for operation of the device without operator
panel and for connection of the PC operator interface
C73195-A100-B65-1
RS485 adapter cable
Name
Order Number
Y-adapter cable for devices with RS485 interface and
sub-D connector on 2x RJ45 sub-miniature connector
for a RS485 bus setup with patch cables. 2–core
twisted, shielded, length 0.3 m; 1x sub-D pin 9–pole
on 2x RJ45 sub-miniature connector 8–pole
7XV5103-2BA00
IEC 60870-5-103 redundant, RS485 adapter cable
Name
Order Number
Y-adapter cable for devices with redundant IEC
608070-5-103 RS485 interface and RJ45 connector
on 2x RJ45 sub-miniature connector for a RS485 bus
setup with patch cables. 2–core twisted, shielded,
length 0.3 m; 1x RJ45 pin 8–pole on 2x RJ45 sub-
miniature connector 8–pole
7XV5103-2CA00
RS485 Bus connector for RJ45
Name
Order Number
RS485 bus connector with internal resistance 220 Ω
between pin 1 and pin 2; 1x RJ45 pin connector 8–
pole
7XV5103-5BA00
Ordering Information and Accessories
A.3 Accessories
538 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
