Figure E-8 Overcurrent monitoring
[cfc-leistungsueberwachung-020313-kn, 1, en_US]
Figure E-9
Power monitoring
Switchgear Interlocking for 7SJ625/6 and 7SJ64
Standard interlocking for three switching devices (52, Disc. and GndSw):
Default Settings and Protocol-dependent Functions
E.6 Pre-defined CFC Charts
SIPROTEC 4, 7SJ62/64, Manual 609
C53000-G1140-C207-8, Edition 08.2016
