Siemens SIPROTEC 4 User Manual

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
14181 Fail: RTD 8 (broken wire/
shorted) (Fail: RTD 8)
RTD-Box OUT On
Of
f
* * LED BO
14182 RTD 8 Temperature stage
1 picked up (RTD 8 St.1
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14183 RTD 8 Temperature stage
2 picked up (RTD 8 St.2
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14191 Fail: RTD 9 (broken wire/
shorted) (Fail: RTD 9)
RTD-Box OUT On
Of
f
* * LED BO
14192 RTD 9 Temperature stage
1 picked up (RTD 9 St.1
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14193 RTD 9 Temperature stage
2 picked up (RTD 9 St.2
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14201 Fail: RTD10 (broken wire/
shorted) (Fail: RTD10)
RTD-Box OUT On
Of
f
* * LED BO
14202 RTD10 Temperature stage
1 picked up (RTD10 St.1
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14203 RTD10 Temperature stage
2 picked up (RTD10 St.2
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14211 Fail: RTD11 (broken wire/
shorted) (Fail: RTD11)
RTD-Box OUT On
Of
f
* * LED BO
14212 RTD11 Temperature stage
1 picked up (RTD11 St.1
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14213 RTD11 Temperature stage
2 picked up (RTD11 St.2
p.up)
RTD-Box OUT On
Of
f
* * LED BO
14221 Fail: RTD12 (broken wire/
shorted) (Fail: RTD12)
RTD-Box OUT On
Of
f
* * LED BO
14222 RTD12 Temperature stage
1 picked up (RTD12 St.1
p.up)
RTD-Box OUT On
Of
f
* * LED BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ62/64, Manual 707
C53000-G1140-C207-8, Edition 08.2016
