No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
16015 Sum Squared Current
Integral Phase B (ΣI^2t
B=)
Statistics VI
16016 Sum Squared Current
Integral Phase C (ΣI^2t
C=)
Statistics VI
16018 Threshold Sum Squa.
Curr. Int. exceeded
(Thresh. ΣI^2t>)
SetPoint(Sta
t)
OUT On
Of
f
* * LED BO
16019 >52 Breaker Wear Start
Criteria (>52 Wear start)
P.System
Data 2
SP On
Of
f
* * LED BI BO
16020 52 Wear blocked by Time
Setting Failure (52
WearSet.fail)
P.System
Data 2
OUT On
Of
f
* * LED BO
16027 52 Breaker Wear Logic blk
Ir-CB>=Isc-CB (52WL.blk I
PErr)
P.System
Data 2
OUT On
Of
f
* * LED BO
16028 52 Breaker W.Log.blk
SwCyc.Isc>=SwCyc.Ir
(52WL.blk n PErr)
P.System
Data 2
OUT On
Of
f
* * LED BO
16029 Sens.gnd.flt. 51Ns
BLOCKED Setting Error
(51Ns BLK PaErr)
Sens. Gnd
Fault
OUT On
Of
f
* * LED BO
16030 Angle between 3Vo and
INsens. (φ(3Vo,INs) =)
Sens. Gnd
Fault
VI ON
OF
F
16034 50Ns-1 not in tripping
range (50Ns-1n.TRrange)
Sens. Gnd
Fault
OUT On
Of
f
* * LED BO
16035 50Ns-2 not in tripping
range (50Ns-2n.TRrange)
Sens. Gnd
Fault
OUT On
Of
f
* * LED BO
17565 >Blocking of the offset
supervision (>Blk.offset
s.)
Device,
General
SP On
Of
f
* * LED BI BO
17566 Disturbance CFC Source
(Dist.CFC Src)
Device,
General
VI O
N
OF
F
30053 Fault recording is running
(Fault rec. run.)
Osc. Fault
Rec.
OUT * * * LED BO
31000 Q0 operationcounter=
(Q0 OpCnt=)
Control
Device
VI *
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ62/64, Manual 709
C53000-G1140-C207-8, Edition 08.2016
